Bulldog Winch 2,000lb Utility Winch
$99.99
Bulldog Winch 2,000lb Utility Winch
SKU2644947
EID 15008
BrandBulldog Winch Co LLC
Compact, light-duty utility winch with 1.0-hp, permanent magnet motor pulls lightweight objects short distances. Built-in plate lets you mount winch to any stable surface. Includes 50' wire rope and hand-held remote with integrated relay switch.
- 2000lb Winch with over-size hand held controller
- Powers load IN & OUT
- Freespooling for quick rope deployment
- Small size with 2-bolt mounting makes it easy to mount even in small spaces
- Hand controller with integrated switch/movement and wiring easily connects to winch and battery
MOTOR | 1.0HP 12vDC PERMANENT MAGNET |
CONTROLLER | HAND HELD WITH 6FT LEAD TO BATTERY & 4FT LEAD TO MOTOR INTEGRATED SWITCH/MOVEMENT WIRELESS: NOT AVAILABLE |
GEAR TRAIN | PLANETARY |
GEAR RATIO | 153:1 |
CLUTCH | FREESPOOLING |
BRAKE | DYNAMIC |
WIRE ROPE DIA X L | 5/32" X 50' (4mm X 15.2m) |
DRUM DIA X L | 1.25" X 2.83" (31.75 X 72mm) |
OVERALL DIMENSIONS (LxWxH) | 11.2 X 4.1 X 4.1" (284.5 X 104.1 X 104.1mm) |
MOUNTING BOLT PATTERN | 2-BOLT 3.15" ON CENTER LINE OF DRUM |
WARRANTY | 2 YEAR LIMITED |
LINE PULL LBS | LINE SPEED FT/MIN | CURRENT A |
---|---|---|
0 | 10.5 | 8 |
500 | 9.2 | 30 |
1000 | 7.2 | 60 |
1500 | 5.2 | 90 |
2000 | 2.9 | 120 |
LAYER | RATED LINE PULL LBS | TOTAL ROPE ON DRUM FT |
---|---|---|
1 | 2000 | 6.6 |
2 | 1630 | 14 |
3 | 1380 | 23.5 |
4 | 1190 | 35 |
5 | 1050 | 47 |
6 | 940 | 50 |
